DPP-CTS2432#

The documentation of our iLCD JPro series can be downloaded as a PDF file here:

To jump to downloads click here:

LCD#

Item	DPP-CTS2432
Screen Size	2.8 inch
Display Resolution	240 x RGB x 320 dots
Dot Pitch	0.06 (H) x 0.18 (V) mm
Active Area	43.2 (H) x 57.6 (V) mm
Display Mode	Normally white / Transmissive
Pixel Arrangement	RGB-Strip
Display Color	262 k (Display) / 64k (Controller)
Backlight ¹)	White LED, typical lifetime 20.000 hours
Brightness typ.	300 cd/m²
Contrast ratio typ.	400
Viewing Direction	6 O’clock
Touch Screen	4-wire resistive

Note:

¹) Brightness decreased to be 50% of the initial value. Life time; mean time before failure at normal temperature (25°C) and normal humidity (60%)

Item	DPP-CTS2432
Connectivity	USB 2.0 / 1 x RS232 3.3V / I²C / SPI
Keyboard	matrix scanning for up to 128 keys
Outputs	up to 16 outputs/LEDs (on/off/blink with user selectable blink frequency) ¹)
Inputs	up to 16 ¹)
ADC	up to 4 (12 bit with range of 0 .. 3.0V) ¹)
Relays/PWM	up to 2 ¹)
Real-Time Clock	Yes
Flash Memory	2 Mbyte for fonts, graphics, macros and text templates
iLCD controller	DPC3050 operating at 100 MHz

Note:

¹) Fully customizable assignments of inputs, outputs, ADCs, Relays, PWMs and keyboard columns

Item	Symbol	Min.	Typ.	Max.	Unit
Supply Voltage	V_CC	3.2	5.0	5.25	V
Input Voltage H Level ¹)²)	V_IH	2.4	-	3.3	V
Input voltage L Level ¹)	V_IL	0.0	-	0.8	V
Output current for digital outputs	I_OUT			3.5	mA
Vbatt current	I_Vbatt		28		µA
Current consumption display switched off @ V_CC = 5V ³)	I_CC		70		mA
Current consumption display on, backlight off @ V_CC = 5V ³)⁴)	I_CC		71		mA
Current consumption with display+backlight @ V_CC = 5V ³)⁴)⁵)	I_CC		185		mA

Notes:

¹) For digital inputs only

²) Digital inputs are 5-volt tolerant

³) No I/O ports active

⁴) All pixel set to white color

⁵) Backlight intensity 100%

DPP-CTS2432 connections (view from PCB side) See Pin Descriptions

DPP-CTS2432 dimensions in mm
